Magellan 3410 Fixed Retail Scanner

Magellan 3410 Fixed Retail Scanner

The Magellan 3450VSi is the perfect fixed retail scanner for Point of Sale, mobile marketing, age verification, and 2D bar codes.

Category:

Description

The Magellan 3410VSi is perfect for Point of Sale, mobile marketing, age verification, and 2D bar codes. It boasts a large field of view and superb imaging capabilities, delivering superior performance on all types of bar codes, including poor quality or out-of-spec bar codes. The Magellan 3410VSi uses the same cables, mounts and exterior plastics as the Magellan 3450VSi, making it easy to integrate into existing installations.

  • Advanced digital imaging provides class-leading performance and reliability
  • Seamless 1D, 2D and Digimarc® digital watermark reading
  • Smoothly reads all bar codes, whether displayed on cell phones or printed
  • Subtle, adaptive illumination for user comfort
  • Solid-state electronics for silent operation and superior reliability
  • Powers from single Type A USB port- 2.5 W, available Magellan Customer Service Scanner (CSS) with omni-mount for reading cell phones, coupons and loyalty cards
  • Software driven – flexible and upgradeable
  • Image capture
  • Micro SD card slot
  • Multiple interfaces in every unit
  • Powered USB auxiliary port – Not enabled when connected to 5V USB Type A host port
  • Checkpoint Systems and Tyco Sensormatic EAS compatible
  • Diagnostics reporting
  • EASEOFCARE Service Plans offer a wide range of service options to protect your investment, ensuring maximum productivity and ROI
Decoding Capability
1D / Linear Codes Autodiscriminates all standard 1D codes including GS1 DataBar™ linear codes.
2D Codes Aztec Code, Data Matrix, QR Code
Stacked Codes GS1 DataBar Composites; GS1 DataBar Expanded
Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked
Omnidirectional; Micro PDF417, PDF417
Digital Watermarks Optional support for Digimarc® Barcodes / GS1 DW
Code
Electrical
Power Requirements AC Input: 100-240 VAC, 50-60 Hz
DC Input: 5-12V
Power Consumption Maximum: 2.25W @ 5V; 3.3W @ 12V
Typical (RMS): 1.6W @ 5V; 2.1W @ 12V
Sleep Mode (RMS): 0.95W @ 5V; 1.25W @ 12V
Environmental
Ambient Light 0 to 86,100 lux
ESD Protection
(Air Discharge)		 25 kV
Humidity (Non-Condensing) 5 – 95%
Particulate and Water
Sealing		 IP52
Temperature Operating: 10 to 40 °C / 50 to 104 °F
Storage/Transport: -40 to 70 °C / -40 to 158 °F
Interfaces
Interfaces OEM (IBM) USB; RS-232; USB Keyboard, USB Com,
USB TEC
Auxiliary Ports Powered Type A USB (USB Com requires power
supply or 12V Host power)
Physical Characteristics
Dimensions Magellan Model 3410VSi:
13.7 x 15.2 x 9.4 cm / 5.4 x 6.0 x 3.7 in
Weight 0.6 kg /1.3 lb
Reading Performance
Image Capture Graphic Formats: BMP, JPEG
Image Sensor 1 MP; 1280 x 800 pixels; Graphic Formats: JPEG, BMP
Light Source Multiple diffused LEDs, orientation and wavelength
optimized for eye comfort
Print Contrast Ratio
(Minimum)		 25%
Read Height 14.0 cm / 5.5 in
Read Rate (Maximum) 30 Million pixels per second
Reading Angle Pitch: +/- 65°; Roll (Tilt): 0 – 360°; Skew (Yaw): +/- 75°
Reading Indicators Audio beeper with adjustable tone and volume;
Good Read LED; Good Transmission
Resolution (Maximum) 5 mil
Reading Ranges
Typical Depth of Field Printing resolution, symbol length, scan angle,
contrast and ambient light dependent.

1D / Linear Codes
5 mils: 0 to 6.4 cm / 0 to 2.5 in
10 mils: 0 to 15.2 cm / 0 to 6.0 in
13 mils: 0 to 20.3 cm / 0 to 8.0 in

2D Codes (Optional)
6.6 mils: PDF: 0 to 5.1 cm / 0 to 2.0 in
10 mils: PDF: 0 to 12.7 cm / 0 to 5.0 in
10 Mils: Data Matrix: 0 to 6.4 cm / 0 to 2.5 in
20 Mils: Data Matrix: 0 to 18.0 cm / 0 to 7.0 in
Safety & Regulatory
Agency Approvals The product meets necessary safety and regulatory
approvals for its intended use.The Quick Reference Guide for this product can be
referred to for a complete list of certifications.
Environmental Compliance Complies to China RoHS; Complies to EU RoHS
LED Classification EN62471 and IEC62471 Lamp Illumination
Exempt Group
Utilities
Scanalyzer Magellan Scanalyzer configuration software is
available for download at www.datalogic.com.
OPOS / JavaPOS OPOS and JavaPOS utilities are available for
download at no charge.
Warranty
Warranty 3-Year Factory Warranty
